Titan troyniklari

Titan troyniklari

Material: CP titanium va titanium qotishmasi: Gr.1, Gr.2, Gr.5, Gr.7, Gr.9, Gr.12

So'rov yuborish

Xususiyatlari

Material:

CP titanium va titanium qotishmasi: Gr.1, Gr.2, Gr.5, Gr.7, Gr.9, Gr.12

Standart:

ASTM, AMSE/ANSI va DIN

Hajmi:

1/2" dan 24" gacha NPS

Titan troyniklarining tavsifi

Titan troyniklari quvurlar tarmog'ini yaratish uchun quvurlar, nasoslar, vallar va boshqa quvur qismlarini bir-biriga ulash uchun ishlatiladi. Ular tekshirish va tozalashni osonlashtirish uchun quvur tarmoqlarini ajratish uchun ishlatiladi va quvurlarga vidalanishi yoki payvandlanishi mumkin. Flanesli bo'g'inlar, odatda, ular orasidagi qistirma bilan murvat bilan biriktiriladi.

SSC keng assortimentdagi umumiy gardishlarni ishlab chiqaradi va zaxiralaydi, jumladan:

● Payvandlash bo'yin gardish

● Slip On Flange

● Rozetkali payvand gardish

● Lap qo'shma gardish

● Tishli gardish

● Ko'r gardish

● Orifis gardish

● Ko‘zoynak bo‘shligi

Flanjlar odatda quvur troyniklari va gardishli armatura uchun ASME B16.5 standartiga muvofiq belgilanadi va ishlab chiqariladi va biz zudlik bilan jo'natish uchun bir qator zaxira buyumlarini saqlaymiz. Standart gardishlarga qo'shimcha ravishda biz buyurtma bo'yicha maxsus troyniklarni, jumladan reduktor / kengaytiruvchi gardishlarni, uzun bo'yinli va teshikli troyniklarni ishlab chiqarishimiz mumkin.

Titan troyniklari kuchli, engil va korroziyaga chidamliligi bilan mashhur. Boshqa metall gardishlar bilan solishtirganda ajralib turadigan xususiyatlardan biri shundaki, titanium slip-on gardishlar zichligi 4,51 g / sm3 bo'lgan eng yuqori kuch va og'irlik nisbatiga ega. Misol tariqasida, 5-sinf titan 316 zanglamaydigan po'latdan 4 baravar kuchliroq va og'irligi deyarli yarmiga teng. Bu titaniumli uzun payvandlangan bo'yin gardishlarini neft va gaz (teshik), harbiy va sport buyumlari kabi engil vazn va mukammal quvvat talab qiladigan ilovalar uchun ideal qiladi. Titan ko'r gardishlari yuqori samarali qotishma bo'lib, elektro cürufni qayta ishlash (ESR) jarayoni orqali ikki marta erishdan katta foyda keltiradi. Ushbu titaniumli yuqori markazli ko'r gardishlarda payvandlashdan keyingi issiqlik bilan ishlov berishga hojat yo'q. Biroq, payvandlashdan keyin yaxshilab tozalash titaniumli payvand chokining korroziyaga chidamliligi uchun juda muhimdir, aks holda ifloslanish va mo'rtlashish xavfi mavjud.

SSC titanium gardishlar, armatura va moslashtirilgan komponentlarning juda ko'p turlarini taklif etadi. Bir funt uchun funt sterling asosida titan kabi kuchli, tijoratda mavjud bo'lgan material yo'q.

2-darajali titanium quvur klapanlari va armatura sanoatida eng ko'p talab qilinadigan, katta quvvat va korroziyaga chidamlilik xususiyatlariga ega. Mahsulotlarimizning aksariyati ASTM B381 2-darajali bo'ladi, chunki uning mavjudligi va oksidlanishga chidamliligi, xuddi 316 zanglamaydigan po'latdan foydalanadigan dengiz uskunalari kabi. Biz, shuningdek, yuqori haroratlarda yuqori quvvatni saqlaydigan va egiluvchanligi va payvandlanishi bilan mashhur bo'lgan 12-sinf titanni taklif qilamiz. Titan ko'pincha yuqori harorat va bosimli xizmat ko'rsatishni talab qiladigan, ammo og'irligi kam bo'lgan ilovalarda qo'llaniladi. Ba'zi ajoyib misollar - aviatsiya sanoati uchun komponentlar (havo korpusi ramkalari) va harbiylarning zamonaviy jihozlari. Dengiz va xlorid ilovalarida mukammal korroziyaga chidamlilik xususiyatlarini hisobga olgan holda, titanium gardishlar dengizda burg'ulash komponentlari va issiqlik almashtirgichlar majmuasi sifatida ham mashhur.

Titanium va uning qotishmalari mukammal mexanik xususiyatlarini saqlab qolgan holda issiq yoki sovuq shakllanish qobiliyatiga ega. Shu bilan birga, titan oddiy po'latdan ancha kichikroq (taxminan 40-45 foizga kam). Alyuminiy kabi engil bo'lmasa-da, bizning titan gardishlarimiz va armaturalarimiz payvandlash va o'rnatish jarayonida biroz osonroq ishlaydi.

Titan flanes uchun spetsifikatsiya

Titanli slip-on gardish

image003(001)

Titan slip-on gardish (ko'tarilgan yuz)
1/2" dan 24" gacha NPS

Sinf 150 titaniumli slip-on gardish

Sinf 150 titaniumli slip-on gardish

Nom. Quvur hajmi

Flanj diametri.

Flanj qalinligi

Hub Dia. Bazada

Ko'tarilgan yuz Dia.

Teshiklar soni

Dia. Boltlar haqida

Dia. Bolt doirasidan

Teshik Dia.

Hub orqali uzunlik

1/2

3-1/2

7/16

1-3/16

1-3/8

4

1/2

2-3/8

0.88

5/8

3/4

3-7/8

1/2

1-1/2

1-11/16

4

1/2

2-3/4

1.09

5/8

1

4-1/4

9/16

1-15/16

2

4

1/2

3-1/8

1.36

11/16

1-1/4

4-5/8

5/8

2-5/16

2-1/2

4

1/2

3-1/2

1.70

13/16

1-1/2

5

11/16

2-9/16

2-7/8

4

1/2

3-7/8

1.95

7/8

2

6

3/4

3-1/16

3-5/8

4

5/8

4-3/4

2.44

1

2-1/2

7

7/8

3-9/16

4-1/8

4

5/8

5-1/2

2.94

1-1/8

3

7-1/2

15/16

4-1/4

5

4

5/8

6

3.57

1-3/16

3-1/2

8-1/2

15/16

4-13/16

5-1/2

8

5/8

7

4.07

1-1/4

4

9

15/16

5-5/16

6-3/16

8

5/8

7-1/2

4.57

1-5/16

5

10

15/16

6-7/16

7-5/16

8

3/4

8-1/2

5.66

1-7/16

6

11

1

7-9/16

8-1/2

8

3/4

9-1/2

6.72

1-9/16

8

13-1/2

1-1/8

9-11/16

10-5/8

8

3/4

11-3/4

8.72

1-3/4

10

16

1-3/16

12

12-3/4

12

7/8

14-1/4

10.88

1-15/16

12

19

1-1/4

14-3/8

15

12

7/8

17

12.88

2-3/16

14

21

1-3/8

15-3/4

16-1/4

12

1

18-3/4

14.14

2-1/4

16

23-1/2

1-7/16

18

18-1/2

16

1

21-1/4

16.16

2-1/2

18

25

1-9/16

19-7/8

21

16

1-1/8

22-3/4

18.18

2-11/16

20

27-1/2

1-11/16

22

23

20

1-1/8

25

20.20

2-7/8

24

32

1-7/8

26-1/8

27-1/4

20

1-1/4

29-1/2

24.25

3-1/4

Sinf 300 titaniumli slip-on gardish

SS 300 titan gardish

Nom. Quvur hajmi

Flanj diametri.

Flanj qalinligi

Hub Dia. Bazada

Ko'tarilgan yuz Dia.

Teshiklar soni

Dia. Boltlar haqida

Dia. Bolt doirasidan

Teshik Dia.

Hub orqali uzunlik

1/2

3-3/4

9/16

1-1/2

1-3/8

4

1/2

2-5/8

0.88

7/8

3/4

4-5/8

5/8

1-7/8

1-11/16

4

5/8

3-1/4

1.09

1

1

4-7/8

11/16

2-1/8

2

4

5/8

3-1/2

1.36

1-1/16

1-1/4

5-1/4

3/4

2-1/2

2-1/2

4

5/8

3-7/8

1.70

1-1/16

1-1/2

6-1/8

13/16

2-3/4

2-7/8

4

3/4

4-1/2

1.95

1-3/16

2

6-1/2

7/8

3-5/16

3-5/8

8

5/8

5

2.44

1-5/16

2-1/2

7-1/2

1

3-15/16

4-1/8

8

3/4

5-7/8

2.94

1-1/2

3

8-1/4

1-1/8

4-5/8

5

8

3/4

6-5/8

3.57

1-11/16

Titan ko'r gardish (ko'tarilgan yuz)

image005(001)

Titan ko'r gardish

1/2"-24" ASME B16.5

12" dan 60" gacha (MSS)

Sinf 150 dan 2500 gacha

Sinf 150 titaniumli ko'r gardish

Sinf 150 titaniumli ko'r gardish

Nom. Quvur hajmi

Flanj diametri.

Flanj qalinligi

Ko'tarilgan yuz Dia.

Teshiklar soni

Dia. Boltlar

Dia. Bolt doirasidan

1/2

3-1/2

7/16

1-3/8

4

1/2

2-3/8

3/4

3-7/8

1/2

1-11/16

4

1/2

2-3/4

1

4-1/4

9/16

2

4

1/2

3-1/8

1-1/4

4-5/8

5/8

2-1/2

4

1/2

3-1/2

1-1/2

5

11/16

2-7/8

4

1/2

3-7/8

2

6

3/4

3-5/8

4

5/8

4-3/4

2-1/2

7

7/8

4-1/8

4

5/8

5-1/2

3

7-1/2

15/16

5

4

5/8

6

3-1/2

8-1/2

15/16

5-1/2

8

5/8

7

4

9

15/16

6-3/16

8

5/8

7-1/2

5

10

15/16

7-5/16

8

3/4

8-1/2

6

11

1

8-1/2

8

3/4

9-1/2

8

13-1/2

1-1/8

10-5/8

8

3/4

11-3/4

10

16

1-3/16

12-3/4

12

7/8

14-1/4

12

19

1-1/4

15

12

7/8

17

14

21

1-3/8

16-1/4

12

1

18-3/4

16

23-1/2

1-7/16

18-1/2

16

1

21-1/4

18

25

1-9/16

21

16

1-1/8

22-3/4

20

27-1/2

1-11/16

23

20

1-1/8

25

24

32

1-7/8

27-1/4

20

1-1/4

29-1/2

Sinf 300 titaniumli ko'r gardish

Sinf 300 titaniumli ko'r gardish

Nom. Quvur hajmi

Flanj diametri.

Flanj qalinligi

Ko'tarilgan yuz Dia.

Teshiklar soni

Dia. Boltlar haqida

Dia. Bolt doirasidan

1/2

3-3/4

9/16

1-3/8

4

1/2

2-5/8

3/4

4-5/8

5/8

1-11/16

4

5/8

3-1/4

1

4-7/8

11/16

2

4

5/8

3-1/2

1-1/4

5-1/4

3/4

2-1/2

4

5/8

3-7/8

1-1/2

6-1/8

13/16

2-7/8

4

3/4

4-1/2

2

6-1/2

7/8

3-5/8

8

5/8

5

2-1/2

7-1/2

1

4-1/8

8

3/4

5-7/8

3

8-1/4

1-1/8

5

8

3/4

6-5/8

Titanli payvand bo'yin gardish


1/2" dan 60" gacha NPS (ANSI) [Faqat ko'tarilgan yuz] 150 dan 2500 gacha sinf
12" dan 60" gacha NPS (MSS) 150 dan 900 gacha [Yuz ko'tarilgan] 300 dan 900 gacha [Ring tipidagi bo'g'inlar]

Sinf 150 titaniumli payvand bo'yin gardish

Sinf 150 titaniumli payvand bo'yin gardish

Nom. Quvur hajmi

Flanj diametri.

Flanj qalinligi

Hub Dia. Bazada

Ko'tarilgan yuz Dia.

Hub Dia. Payvandlash nuqtasida

soni<>

Dia. Boltlar

Dia. Bolt doirasidan

Teshik Dia.

Hub orqali uzunlik

1/2

3-1/2

7/16

1-3/16

1-3/8

0.84

4

1/2

2-3/8

0.62

1-7/8

3/4

3-7/8

1/2

1-1/2

1-11/16

1.05

4

1/2

2-3/4

0.82

2-1/16

1

4-1/4

9/16

1-15/16

2

1.32

4

1/2

3-1/8

1.05

2-3/16

1-1/4

4-5/8

5/8

2-5/16

2-1/2

1.66

4

1/2

3-1/2

1.38

2-1/4

1-1/2

5

11/16

2-9/16

2-7/8

1.90

4

1/2

3-7/8

1.61

2-7/16

2

6

3/4

3-1/16

3-5/8

2.38

4

5/8

4-3/4

2.07

2-1/2

2-1/2

7

7/8

3-9/16

4-1/8

2.88

4

5/8

5-1/2

2.47

2-3/4

3

7-1/2

15/16

4-1/4

5

3.50

4

5/8

6

3.07

2-3/4

3-1/2

8-1/2

15/16

4-13/16

5-1/2

4.00

8

5/8

7

3.55

2-13/16

4

9

15/16

5-5/16

6-3/16

4.50

8

5/8

7-1/2

4.03

3

5

10

15/16

6-7/16

7-5/16

5.56

8

3/4

8-1/2

5.05

3-1/2

6

11

1

7-9/16

8-1/2

6.63

8

3/4

9-1/2

6.07

3-1/2

8

13-1/2

1-1/8

9-11/16

10-5/8

8.63

8

3/4

11-3/4

7.98

4

10

16

1-3/16

12

12-3/4

10.75

12

7/8

14-1/4

10.02

4

12

19

1-1/4

14-3/8

15

12.75

12

7/8

17

12.00

4-1/2

14

21

1-3/8

15-3/4

16-1/4

14.00

12

1

18-3/4

13.25

5

16

23-1/2

1-7/16

18

18-1/2

16.00

16

1

21-1/4

15.25

5

18

25

1-9/16

19-7/8

21

18.00

16

1-1/8

22-3/4

17.25

5-1/2

20

27-1/2

1-11/16

22

23

20.00

20

1-1/8

25

19.25

5-11/16

24

32

1-7/8

26-1/8

27-1/4

24.00

20

1-1/4

29-1/2

23.25

6

Sinf 300 titanium payvand choki bo'yin gardish

Sinf 300 titanium payvand choki bo'yin gardish

Nom. Quvur hajmi

Flanj diametri.

Flanj qalinligi.

Hub Dia. Bazada

Ko'tarilgan yuz Dia.

Hub Dia. Payvandlash nuqtasida

Teshiklar soni

Dia. Boltlar haqida

Dia. Bolt doirasidan

Teshik Dia.

Hub orqali uzunlik

1/2

3-3/4

9/16

1-1/2

1-3/8

0.84

4

2-5/8

1/2

0.62

2-1/16

3/4

4-5/8

5/8

1-7/8

1-11/16

1.05

4

3-1/4

5/8

0.82

2-1/4

1

4-7/8

11/16

2-1/8

2

1.32

4

3-1/2

5/8

1.05

2-7/16

1-1/4

5-1/4

3/4

2-1/2

2-1/2

1.66

4

3-7/8

5/8

1.38

2-9/16

1-1/2

6-1/8

13/16

2-3/4

2-7/8

1.90

4

4-1/2

3/4

1.61

2-11/16

2

6-1/2

7/8

3-5/16

3-5/8

2.38

8

5

5/8

2.07

2-3/4

2-1/2

7-1/2

1

3-15/16

4-1/8

2.88

8

5-7/8

3/4

2.47

3

3

8-1/4

1-1/8

4-5/8

5

3.50

8

6-5/8

3/4

3.07

3-1/8

Titanium Lap qo'shma quvur gardish

1/2" dan 24" gacha NPS, 150 dan 300 gacha

image009(001)

Sinf 150 titanium kran qo'shma quvur gardish

Sinf 150 titanium Lap qo'shma quvur gardish

Nom. Quvur hajmi

Flanj diametri.

Flanj qalinligi

Hub Dia. Bazada

Teshiklar soni

Dia. Boltlar

Dia. Bolt doirasidan

Teshik Dia.

Hub orqali uzunlik

1/2

3-1/2

7/16

1-3/16

4

1/2

2-3/8

0.90

5/8

3/4

3-7/8

1/2

1-1/2

4

1/2

2-3/4

1.11

5/8

1

4-1/4

9/16

1-15/16

4

1/2

3-1/8

1.38

11/16

1-1/4

4-5/8

5/8

2-5/16

4

1/2

3-1/2

1.72

13/16

1-1/2

5

11/16

2-9/16

4

1/2

3-7/8

1.97

7/8

2

6

3/4

3-1/16

4

5/8

4-3/4

2.46

1

2-1/2

7

7/8

3-9/16

4

5/8

5-1/2

2.97

1-1/8

3

7-1/2

15/16

4-1/4

4

5/8

6

3.60

1-3/16

3-1/2

8-1/2

15/16

4-13/16

8

5/8

7

4.10

1-1/4

4

9

15/16

5-5/16

8

5/8

7-1/2

4.60

1-5/16

5

10

15/16

6-7/16

8

3/4

8-1/2

5.69

1-7/16

6

11

1

7-9/16

8

3/4

9-1/2

6.75

1-9/16

8

13-1/2

1-1/8

9-11/16

8

3/4

11-3/4

8.75

1-3/4

10

16

1-3/16

12

12

7/8

14-1/4

10.92

1-15/16

12

19

1-1/4

14-3/8

12

7/8

17

12.92

2-3/16

14

21

1-3/8

15-3/4

12

1

18-3/4

14.18

3-1/8

16

23-1/2

1-7/16

18

16

1

21-1/4

16.19

3-7/16

18

25

1-9/16

19-7/8

16

1-1/8

22-3/4

18.20

3-13/16

20

27-1/2

1-11/16

22

20

1-1/8

25

20.25

4-1/16

24

32

1-7/8

26-1/8

20

1-1/4

29-1/2

24.25

4-3/8

Sinf 300 titaniumli qo'shma quvur gardish:

Sinf 300 titaniumli qo'shma quvur gardish

Nom. Quvur hajmi

Flanj diametri.

Flanj qalinligi.

Hub Dia. Bazada

Teshiklar soni

Dia. Boltlar haqida

Dia. Bolt doirasidan

Teshik Dia.

Hub orqali uzunlik

1/2

3-3/4

9/16

1-1/2

4

1/2

2-5/8

0.90

7/8

3/4

4-5/8

5/8

1-7/8

4

5/8

3-1/4

1.11

1

1

4-7/8

11/16

2-1/8

4

5/8

3-1/2

1.38

1-1/16

1-1/4

5-1/4

3/4

2-1/2

4

5/8

3-7/8

1.72

1-1/16

1-1/2

6-1/8

13/16

2-3/4

4

3/4

4-1/2

1.97

1-3/16

2

6-1/2

7/8

3-5/16

8

5/8

5

2.46

1-5/16

2-1/2

7-1/2

1

3-15/16

8

3/4

5-7/8

2.97

1-1/2

3

8-1/4

1-1/8

4-5/8

8

3/4

6-5/8

3.60

1-11/16

Darajalar va xususiyatlar

Titan darajasi

Kimyoviy tarkibi

Xususiyatlari

1-sinf

R50250

Tijoriy jihatdan toza

C 0.10 maks
Fe 0.20 maks
H 0.015 maks
N 0.03 maks
O 0.18 maks
Ti qolgan

MIN. TURISH 35 KSI
MIN. Hosildorlik 25 KSI
QATTIQLIK 14.9
SHUVLASH MODULI 103 GPA
POISSON Ratsioni 0.34-0.40

2-sinf

R50400

Tijoriy jihatdan toza

C 0.10 maks
Fe 0.30 maks
H 0.015 maks
N 0.03 maks
O 0.25 maks
Ti qolgan

MIN. TURISH 50 KSI
MIN. Hosildorlik 40 KSI
QATTIQLIK 14.9
SHUVLASH MODULI 103 GPA
POISSON Ratsioni 0.34-0.10

5-sinf

R56400

Ti-6Al-4V

AI 5.5-6,75 maks
C 0.10 maks
Fe 0.40 maks
H 0.015 maks
N 0.05 maks
O 0.20 maks
V 3.5-4.5
Ti qolgan

MIN. TURISH 130 KSI
MIN. Hosildorlik 120 KSI
QATTIQLIK 16.4
SHUVLASH MODULI 114 GPA
POISSON Ratsioni 0.30-0.33

7-sinf

R52400

Ti-0.15Pd

Pd 0.12-0.25 maks
C 0.10 maks
Fe 0.30 maks
H 0.015 maks
N 0.03 maks
O 0.25 maks
Ti qolgan

MIN. TURISH 50 KSI
MIN. Hosildorlik 40 KSI
QATTIQLIK 14.9
SHUVLASH MODULI 103 GPA
POISSON Ratsioni 0.37

9-sinf

R56320

Ti-3Al-2.5V

AI 2.5-3.5
C 0.05 maks
Fe 0.25 maks
H 0.013 maks
N 0.02 maks
O 0.12 maks
V 2.0-3.0
Ti qolgan

MIN. TURISH 90 KSI
MIN. Hosildorlik 70 KSI
QATTIQLIK 13.0
SHUVLASH MODULI 107 GPA
POISSON Ratsioni 0.34

12-sinf

R53400

Ti-0.3Mo-0.8Ni

C 0.08 maks
Fe 0.30 maks
H 0.0135 maks
Oy 0.2-0.4
N 0.03 maks
O 0.25 maks
Ti qolgan

MIN. TURISH 70 KSI
MIN. Hosildorlik 50 KSI
QATTIQLIK 14.9
SHUVLASH MODULI 103 GPA
POISSON Ratsioni 0.28

Titan gardish ilovalari va tegishli sanoat

● Quvurlar tarmog‘ini yaratish uchun quvurlarni, nasoslarni, vanalarni va boshqa quvur qismlarini bir-biriga ulang

● Tekshirish va tozalashni osonlashtirish uchun quvurlar tarmoqlarini ajrating

● Suvni tozalash

● Tuzsizlantirish

● Energiya ishlab chiqarish

● Dengiz

● Kimyoviy qayta ishlash

● Neft va gazni qidirish


Issiq teglar: titanium flanes, Xitoy, etkazib beruvchilar, sotib olish, sotish, Xitoyda ishlab chiqarilgan

Sizga ham yoqishi mumkin

(0/10)

clearall
